Defiance Tools by Stanley

Collection • Identification • Research

What began as a hunt for a few inexpensive old hand planes became one of the deepest rabbit holes on Idle Hands Workshop. This page is my ongoing attempt to document the Stanley Defiance tool line, identify the planes and their variations, track my collection, preserve the research I’ve accumulated and make the information easier for the next person who finds an anonymous gray plane at a flea market and wonders what exactly they have.

18 Documented Plane Variants in the Collection

1 Question-Mark Model: The 1202

1939 Stanley Catalog #139 Research Anchor

Ongoing The Rest of the Defiance Tool Line

Jump Into the Research

Idle Hands Workshop collection of Defiance by Stanley hand planes

The Defiance plane collection — the result of a rabbit hole that turned out to be considerably deeper than expected.

So What Was Stanley Defiance?

Stanley built its reputation on tools intended for working tradesmen, but not every customer needed—or wanted to pay for—the company’s premium offerings. By the end of the 1920s, Stanley was selling the Defiance line as a lower-cost family of tools aimed largely at homeowners, farmers, hobbyists and occasional users who still wanted the Stanley connection without paying the price of the main professional lines.

The Defiance name can be confusing because it predates the later Stanley budget line. Earlier tools associated with Defiance and the Bailey Tool Company belong to a different chapter of plane history and should not automatically be grouped with the later gray Stanley Defiance tools documented here.

The later Defiance line was far larger than just hand planes. Period references show braces, drills, hammers, levels, screwdrivers, squares, chisels, vises, saws, wrenches and other everyday tools. By the late 1930s the range had expanded into an impressive catalog of equipment intended to cover most ordinary household, farm and workshop repair work.

The important thing to remember is that “budget line” does not automatically mean “useless tool.” Properly cleaned, adjusted and sharpened, many Defiance tools are perfectly capable users. Their quirks are also part of what makes collecting them interesting.

That is ultimately what pulled me into this collection. Defiance tools sit in an odd corner of Stanley history: common enough that they were never treated with the reverence given to premium Stanley planes, yet varied and poorly documented enough that identifying them can become a serious research project. Just when the list seems complete, another variation tends to appear.

1939 Stanley Catalog No. 139

The Catalog That Changed the Project

Near the end of 2023 I obtained an original Stanley Tools Catalog No. 139 from 1939. The final eight pages are devoted to Defiance tools, giving this project something far better than scattered auction listings and secondhand descriptions: an original Stanley-era reference showing what was actually being offered at the time. That catalog has become one of the primary anchors for the broader Defiance research.

Identifying a Defiance Plane

Unfortunately, Stanley did not make identification especially convenient. Some examples are clearly marked and others seem almost determined to hide what they are.

Flat-Sided Wooden Totes

Many Defiance bench planes use handles with noticeably flat sides. Earlier examples may use better wood, while later examples may be stained to imitate rosewood or simply painted black. Some totes carry a DEFIANCE stamp, sometimes highlighted with gold-colored paint.

Rougher Castings

Compared with Stanley’s better-known premium lines, Defiance planes can show visible casting seams, machining marks and less refined finishing. Those marks are not necessarily later damage; sometimes they are part of how the plane left the factory.

Lever Caps & Frogs

Defiance lever caps and frog assemblies can differ from regular Bailey-pattern Stanley parts. Later integral-frog models simplify the design even further, eliminating the familiar separate adjustable frog altogether.

Iron & Casting Marks

The cutting iron may carry the DEFIANCE name and sometimes a model number. Many bodies are marked MADE IN U.S.A. behind the front knob, but individual examples vary enough that dimensions remain one of the most useful identification tools.

Defiance Plane Reference Guide

This is the working plane list I use for identification and collection tracking. Measurements are particularly useful because many examples have lost their markings over the decades. Production dates are intentionally not treated as settled here where surviving references disagree.

Model	Type	Length	Cutter	Identification Notes	Status
1202	Bench?	7½”	1¾” or 1⅝”	Reported model; existence remains unconfirmed.	Research
1203	Smoothing	8″	1¾”	Smooth sole.	Owned
1203C	Smoothing	8″	1¾”	Corrugated sole.	Owned
1204	Smoothing	9″	2″	Smooth sole.	Owned
1204C	Smoothing	Approx. 9¼”	2″	Corrugated sole.	Owned
1205	Jack	14″	2″	Smooth sole.	Owned
1205C	Jack	14″	2″	Corrugated sole.	Owned
1213	Bench	9″	Approx. 1⅝–1¾”	Unusual integral-frog / wedge construction.	Owned
1213½	Bench	Approx. 9¼”	Approx. 1¾”	Rare integral design with large depth adjuster.	Owned
1220	Block	7″	1⅝”	Traditional block-plane format.	Owned
1243	Smoothing	Approx. 8¼”	1¾”	Later integral-frog style.	Owned
1244	Smoothing	Approx. 9¼”	Approx. 1 13/16″	Later integral-frog style.	Owned
1245	Jack	14″	2″	Later integral-frog style.	Owned
205 / 1245	Block	Approx. 6¼”	Approx. 1 7/16″	Pressed/folded steel construction; model-number oddity.	Owned
1247	Block	Approx. 6½”	1⅝”	Standard finish.	Owned
1247c	Block	Approx. 6½”	1⅝”	Cadmium-coated variation.	Owned
1248	Low-Angle Block	7″	Approx. 1 5/16″	One of multiple distinct planes carrying 1248.	Owned
1248	Block	Approx. 5½”	Approx. 1⅜”	Later, smaller use of the same model number.	Owned
1248A	Block	Approx. 6⅝”	Approx. 1¾”	Another member of the confusing 1248 family.	Owned

A note on the letters: an uppercase C denotes a corrugated sole in this list, while the lowercase c on the 1247c refers to its cadmium coating. On surviving examples that coating may be worn, polished away or covered by later paint, making the variation difficult to identify from photographs alone.

The Ones That Refuse to Follow the Rules

Every good collecting rabbit hole needs a few models that make the identification guide considerably less convenient.

1213 & 1213½

These two are dramatically different from the ordinary Defiance bench-plane pattern. Instead of a conventional separate frog, the blade rests against an integral wedge in the body, and a cross pin helps secure the lever cap.

The 1213 is extremely simple, while the 1213½ adds a very large depth-adjustment mechanism and a different iron. The 1213½ in particular is one of the pieces that turns an inexpensive-tool collection into a serious hunt.

1243, 1244 & 1245

These later planes simplify the familiar bench-plane arrangement by using integral supports instead of the conventional adjustable frog. Adjustment is correspondingly limited compared with a regular Bailey-style Stanley plane.

Their distinctive cross-hatched lever caps and stripped-down construction make them relatively easy to recognize once you know what you are looking at.

The 1248 Problem

The number 1248 is one of the more entertaining ways Stanley made this collection confusing. More than one distinctly different block plane appears under that model number across the history of the line.

This is one reason measurements matter. A seller’s description that simply says “Defiance 1248” may not tell you which 1248 is actually sitting in front of them.

The Mystery 1202

The 1202 remains the question mark. References to it suggest a roughly 7½-inch plane, but I have yet to establish the existence of a physical example strongly enough to call the matter settled.

Until one surfaces with convincing documentation, it stays on the list as a research target rather than an empty hole in the collection.

Defiance Was Much More Than Planes

The hand planes were where this collection started, but Stanley marketed Defiance as a broad household and general-purpose tool line. Each category below has grown enough to deserve its own page, with photographs, model numbers, known variations and whatever research has surfaced so far.

Defiance Restoration Archive

Several planes have their own restoration or research write-ups. Some came from the earlier version of Idle Hands Workshop and currently live in the Wayback Machine, while newer material is being brought onto the current site.

Defiance 1203 Restoration The Frankenplane that turned into a restoration project. Defiance 1204 Restoration Identification, cleanup and restoration of the No. 4-size plane. Defiance 1205 Restoration One of the projects that helped start the larger collection. Defiance 1213½ Hand Plane A closer look at one of the strangest and hardest-to-find planes in the Defiance family.

Research, Catalogs & The Unsolved Stuff

Defiance research is still very much a moving target. Original catalogs, advertisements, surviving tools and collector reports continue to fill gaps—and occasionally create entirely new ones. These pages are where the deeper research lives.

In Search Of… The wanted list: undocumented tools, mystery models, missing examples and the pieces that have not turned up yet. Enter the X-Files → Vintage Catalogs & Advertisements Period catalogs and advertising provide some of the strongest evidence for model numbers, dates, prices, finishes and original tool configurations. Browse the Paper Trail → Defiance Research & Links External references, collector resources, documentation and other useful places for continuing the hunt. Open the Research Desk →

This is a living research archive. Stanley documentation, collector references and surviving examples do not always agree on production dates, measurements or small specifications. Where something can be verified from original catalogs or physical examples, the information will continue to be updated. Where the evidence conflicts, I would rather leave the question open than turn a good guess into a bad historical fact.

Sources & Further Research

This project combines original Stanley material, published collector references, outside research sites and the physical tools themselves. No single source has answered every question, which is part of why this archive continues to evolve.

Major references used during this project include the original Stanley Tools Catalog No. 139 from 1939, Alvin Sellens’ The Stanley Plane, John Walter’s Antique & Collectible Stanley Tools, collector research, period advertisements and surviving examples.

Time Tested Tools The Plane Dealer DATAMP

The goal remains the same: document as much of the Stanley Defiance tool line as I reasonably can, preserve the information I’ve found and continue building the collection. The planes may be essentially complete, but the catalogs have proved just how many other Defiance tools are still out there waiting to turn up at an estate sale, flea market or in a poorly photographed online listing.
